XMG PRO 17

UNCHAIN YOURSELF

As an exceptionally portable, slim and refined gaming laptop, the XMG PRO 17 is an impressive on-the-go performance workstation. A perfect balance of high-end components of the latest generation, a large selection of external interfaces and outstanding mobility define the DNA of this versatile multi-talent. A high-quality aluminium chassis in a classic design gives the notebook a serious appearance, excellent quality and durability. NVIDIA graphics cards up to an efficiency-optimised GeForce RTX 3080 guarantee excellent gaming and GPU acceleration performance. A large battery, long runtimes and a weight of just 2.3 kg complete the mobility-focused XMG PRO 17.

Powerful efficiency

RTX 3000

With the mobile GeForce RTX 3000 laptop graphics cards, NVIDIA once again takes a giant leap in mobile 3D performance. The XMG PRO 17 integrates the RTX 3080 with 16 or RTX 3070 with 8 GB GDDR6 memory, the most powerful models in the efficiency-optimised Max-Q design, which contributes decisively to the design of slim, portable laptops with outstanding gaming performance. Not only are they fundamentally faster than comparable graphics cards from the previous generation, but they also offer significantly improved and future-proof ray tracing performance for upcoming AAA game titles, as well as groundbreaking GPU acceleration for professional applications.

XMG PRO Gaming-Laptop NVIDIA RTX Intel Core i7
XMG PRO Gaming-Laptop NVIDIA RTX Intel Core i7

Eight high performance cores

Intel Core i7-11800H

The Core i7-11800H from the 11th Core generation is one of Intel’s flagship CPUs for gaming and content creation: with eight cores, 16 threads and modern 10nm manufacturing, it holds a top position among the fastest mobile processors currently available. Intel’s move to the fundamentally revised Tiger Lake architecture is accompanied by a multitude of innovations, introducing some of the latest technologies to the PRO range for the first time. For example, the graphics card and the SSD work via PCI Express 4.0, benefiting from significantly faster connections and higher data throughput. A further innovation is the introduction of Thunderbolt 4.

Rapid
300 Hz IPS display

With a refresh rate of 300 Hz, the Full HD IPS display (1920 x 1080 pixels) is one of the fastest models currently available. For competitive esports games such as CS: GO, Rocket League or Rainbow Six Siege, it impresses with excellent response times and, in combination with a fast graphics card from the GeForce RTX-3000 series, offers a tangible advantage: by updating the displayed images more frequently, the display allows players to react to the action in the decisive fraction of a second. Typical for IPS, the display convinces with high viewing angle stability, intense colours, good black levels and first-class contrast.

XMG PRO L21 LP FEAT 02 300hz wqhd EN
True colour
4K IPS display

A 100 per cent coverage of the extended Adobe RGB colour gamut, high-resolution 4K display with 3840 x 2160 pixels and a high-quality IPS panel: The UHD display targets the sophisticated demands of ambitious and professional users from the field of photo, image and video editing. The additional, qualitative features include a high viewing angle stability, an intensive colour display and very good black levels paired with a high-contrast display.

XMG PRO L21 LP FEAT 02 IPS wqhd EN
Rapid
300 Hz IPS display

With a refresh rate of 300 Hz, the Full HD IPS display (1920 x 1080 pixels) is one of the fastest models currently available. For competitive esports games such as CS: GO, Rocket League or Rainbow Six Siege, it offers excellent response times and, in combination with a fast graphics card from the GeForce RTX 3000 series, offers a tangible advantage; by updating the displayed images more frequently, the display allows players to react to the action in the decisive fraction of a second. With IPS technology, the display excels with high a wide viewing angle, intense colours, good black levels and first-class contrast.

XMG PRO L21 LP FEAT 02 IPS wqhd mobile EN
True colour
4K IPS display

A 100 per cent coverage of the extended Adobe RGB colour gamut, high-resolution 4K display with 3840 x 2160 pixels and a high-quality IPS panel: The UHD display targets the sophisticated demands of ambitious and professional users from the field of photo, image and video editing. The additional, qualitative features include a high viewing angle stability, an intensive colour display and very good black levels paired with a high-contrast display.

XMG PRO 15 LP FEAT 02 UHD OLED wqhd mobile

Versatile and extremely fast

THUNDERBOLT 4

Thunderbolt 4 is the perfect high-end interface for the fastest possible data transfer and functional expansion of the laptop. The record-breaking performance and versatility of the port is not only designed for copying large amounts of data to and from the fastest external SSDs at up to 40 Gbps: it is also the ideal basis for plugging in the most powerful docking stations available, mating the XMG PRO 17 to a complete working environment via just one cable – including multi-monitor setups, network connection, printer, mouse and keyboard.

Thunderbolt 4
40  Gbit/s
XMG PRO 15 Gaming-Laptop Thunderbolt 3

Connection options for

3 EXTERNAL DISPLAYS

Especially in professional environments, but increasingly also in private gaming and streaming setups, multi-monitor configurations are standard. The XMG PRO 15 not only offers extended connectivity for additional displays via the DisplayPort stream of the Thunderbolt port, but also features a native, G-SYNC-compatible Mini DisplayPort 1.4 and an HDMI 2.1 connection. This means that nothing stands in the way of comfortable couch gaming on a high-resolution 4K TV with fast 120 Hz technology.

XMG PRO 15 Gaming-Laptop Multi Monitor
XMG PRO 15 Gaming-Laptop Multi Monitor

Sleek

connectivity champion

Despite its less than 20 mm thin chassis, the connectivity options of the XMG PRO 17 leave nothing to be desired. These include a Gigabit LAN port, a Wi-Fi 6 wireless network connection and three USB 3.2 ports. Separate inputs and outputs for headphones and microphone allow maximum flexibility in the choice of audio peripherals; the microphone connection also supports an optical S/PDIF signal.

USB-C          3x USB-A          Mini DP
Thunderbolt 3                                    3.2 Gen1                                   DisplayPort 1.4
USB-C
Thunderbolt 3
3x USB-A
3.2 Gen1
Mini DP
DisplayPort 1.4
XMG PRO Gaming-Laptop connections
XMG PRO Gaming-Laptop connections
XMG PRO 15 Gaming-Laptop Touchpad

Glass touchpad &

RGB keyboard

Maximum input comfort is ensured, with a keyboard suitable for frequent typists featuring a separate numeric keypad and flexibly adjustable RGB per-key backlight, multi-level adjustable brightness and a clearly defined keystroke. This is complemented by a high-quality, precise Microsoft Precision glass touchpad with a generously large gliding surface and two dedicated tactile buttons, providing a comfortable and precise click response.

VIDEOS & TESTS
Play Video
TECHNICAL DETAILS

XPR17L21

  • 15.6″ IPS | 1920×1080 px | 144 Hz | 300 cd/m² | 90 % sRGB | G-SYNC | non-glare
  • 15.6″ IPS | 1920×1080 px | 300 Hz | 300 cd/m² | 100 % sRGB | non-glare
  • 115.6″ OLED | 3840×2160 px | 60 Hz | 400 cd/m² | 100 % sRGB/DCI-P3 | colour calibrated (powered by x-rite) | glare

Intel HM570

Intel Core i7-11800H | 2.3 – 4.6 GHz | 8 cores/16 threads | 24 MB cache | 45 W TDP

  • Intel UHD Graphics | integrated (iGPU)
  • NVIDIA GeForce RTX 3070 | 8 GB GDDR6 | 90 W TGP (+ 15 W Dynamic Boost) | dedicated (dGPU)
  • NVIDIA GeForce RTX 3080 | 16 GB GDDR6 | 90 W TGP (+ 15 W Dynamic Boost) | dedicated (dGPU)

HDMI, Mini DisplayPort connection: direct via dGPU
DP via USB-C connection: iGPU (with NVIDIA Optimus, 2x DP Alt Mode) or direct via dGPU (1x DP Alt Mode) selectable in BIOS
3 external displays directly addressable (more with MST adapter via USB-C or Mini DisplayPort)

VR Ready

2x DDR4 SO-DIMM | up to 64 GB and 3200 MHz | Dual Channel | max. 1.2 V

1x M.2 2280 SSD via PCI Express 4.0 x4 (supports RAID 0/1)
1x M.2 2280 SSD via PCI Express 3.0 x4 (supports RAID 0/1) or SATA III

  • Stereo speakers
  • Smart Amplifier
  • S/PDIF-out (optical)
  • Microphone with noise cancelling
  • Sound Blaster Atlas

Keyboard with per-key RGB backlight and numeric keypad

Microsoft Precision Touchpad, zwei Soft-Touch-Tasten

Left:

  • 2-in-1-Audio (Mic-in + S/PDIF optical)

  • Headphone-out (smartphone-headset compatible)

  • USB-A 3.2 Gen1 (powered)



Rear:

  • Thunderbolt 4/USB-C 3.2 Gen2×1 (DisplayPort: yes, G-SYNC compatible | Power Delivery: no)

  • DC-in

  • HDMI 2.1 (with HDCP 2.3)

  • Mini DisplayPort 1.4 (G-SYNC compatible)



Right:

  • RJ45 Port (LAN)

  • 2x USB-A 3.2 Gen1

  • Realtek Gbit LAN
  • WLAN 802.11a/b/g/n/ac/ax + Bluetooth 5
  • HD webcam
  • Kensington Lock
  • TPM 2.0 (via Intel PTT)

180 watts (145 x 75 x 23 mm | 620 g incl. EU power cable)

  • Changeable 73 Wh Li-Ion-battery (internally screwed)
  • Flexible battery charging function can be activated in BIOS (FlexiCharger)
  • Display lid, top and bottom case made of aluminium
  • Display frame made of plastic
  • 130° display opening angle
  • One-hand opening

ca. 1.99 kg

357.5 x 238 x 19.8 mm (W x D x H)

Laptop (incl. battery), power supply, driver CD/USB-Stick, manual

We continuously provide you with the latest driver versions in the download portal of our company headquarters Schenker Technologies GmbH.

Download here
