XMG PRO 15 AUDIO

BRAKE FOR NOTHING

The XMG PRO 15 audio is for those of you who want to go beyond pure DJing. With enough power to comfortably handle DAW work, VJing, content creation and live streaming while simultaneously being a VR-capable gaming powerhouse, it’s the best of both worlds: there’s really nothing you can’t do with this machine. A 10th generation 8-core Intel processor, paired with the latest NVIDIA graphics cards up to the GeForce RTX 3080 Max-Q, lets you unleash impressive performance – all in a compact, full-body aluminium chassis, weighing in at less than 2 kg.

XMG PRO Audio 15 DJ-Laptop DPC Latency

Flawless performance out of the box

Like the XMG DJ 15, the PRO 15 Audio has been put through its paces and tweaked for optimum performance, ensuring that DPC latency remains below 1 ms out of the box. This isn’t just great for DJs, but also for live performing producers and VJs who want to take advantage of low-latency audio-responsive visuals without worrying about glitches and dropouts. Forget about having to turn off Wi-Fi or Bluetooth to keep things running stable either! It’s all in the hardware – combined with our sleek, completely bloatware-free Windows 10 Pro install with a few essential tweaks baked right in, you won’t have to waste precious time optimizing the system. Just install whatever you need – whether it’s a DAW, DJ software, creative tools, VJ and streaming software, your games or your VR rig – and you’re good to go. We’ve tested it all!

Powerful efficiency

RTX 3000 Max-Q

Despite its sub-20 mm chassis, the connectivity options of the XMG PRO 15 Audio leave nothing to be desired. These include a microSD card reader with fast UHS-II support, a Gigabit LAN port, a Wi-Fi 6 wireless network connection and three USB 3.2 ports for your audio interfaces, DJ mixers and MIDI controllers. Separate inputs and outputs for headphones and microphone allow maximum flexibility with your choice of audio peripherals when you’re not using external hardware; the microphone connection also supports an optical S/PDIF signal.

XMG PRO 15 Gaming-
XMG PRO 15 Gaming-Laptop NVIDIA RTX Intel Prozessor

Powerful

Intel eight-core processor

Intel’s Core i7-10870H offers eight fast Comet Lake cores and processes up to 16 threads simultaneously. The mobile processor from the current tenth Core generation operates with a base and boost clock of 2.2 GHz and up to 5.0 GHz respectively. Thanks to its ample performance reserves, neither the latest multicore-hungry games nor highly parallelised software applications pose a challenge.

All the smoothness

The Full HD 144Hz non-glare IPS display will provide rich colours, high contrast, a brightness of 300 nits and excellent viewing angles while outpacing the waveform rendering capabilities of any DJ software. It simply doesn’t get any smoother!

XMG PRO 15 Audio Gaming Laptop 144 Hz Display
XMG PRO 15 Audio Gaming Laptop 144 Hz Display

Per-key backlit rgb keyboard &

Glass touchpad

The PRO 15 Audio features a keyboard suitable for frequent typists featuring a separate numeric keypad, multi-level adjustable brightness and a clearly defined keystroke. An easily adjustable RGB per-key backlight lets you create entirely custom backlighting layouts for whichever software you use in dark environments such as clubs. This is complemented by a high-quality, precise Microsoft Precision glass touchpad with a generously large gliding surface and two dedicated tactile buttons, providing a comfortable and precise click response.

XMG PRO Audio 15 DJ-Laptop Touchpad

Connection options for

3 EXTERNAL DISPLAYS

Especially in professional environments, but increasingly also in private gaming and live streaming setups, multi-monitor configurations are commonplace. The XMG PRO 15 not only offers extended connectivity for additional displays via the DisplayPort stream of the Thunderbolt 3 port, but also features a native, G-SYNC-compatible Mini DisplayPort 1.4 and an HDMI 2.1 connection. These ultra-resolution display outputs mean that nothing stands in the way of multi-out VJing, live streaming with easy monitoring – or comfortable couch gaming on a high-resolution 4K TV with fast 120 Hz technology.

XMG PRO 15 Gaming-Laptop Multi Monitor
XMG PRO 15 Gaming-Laptop Multi Monitor

By DJs for DJs

Wouldn’t it be nice if you could ask an actual DJ about DJ-specific things? We think so, too – that’s why we’ve got actual DJs, producers and VJs running support for these machines, and they love to help people figure stuff out. Just shoot an e-mail to audio@xmg.gg and you will be taken care of!

XMG PRO Audio 15 DJ-Laptop By DJs for DJs

d

Professional connectivity

Despite its sub-20 mm chassis, the connectivity options of the XMG PRO 15 audio leave nothing to be desired. These include a microSD card reader with fast UHS-II support, a Gigabit LAN port, a Wi-Fi 6 wireless network connection and three USB 3.2 ports for your audio interfaces, DJ mixers and MIDI controllers. Separate inputs and outputs for headphones and microphone allow maximum flexibility with your choice of audio peripherals when you’re not using external hardware; the microphone connection also supports an optical S/PDIF signal.

USB-C          3x USB-A          Mini DP
Thunderbolt 3                                    3.2 Gen1                                   DisplayPort 1.4
USB-C
Thunderbolt 3
3x USB-A
3.2 Gen1
Mini DP
DisplayPort 1.4
XMG PRO 15 Gaming-Laptop Anschlüsse
XMG PRO 15 Gaming-Laptop Anschlüsse
VIDEOS & TESTS
Play Video
TECHNICAL DETAILS

XPR15E21AD

  • 15.6″ IPS | 1920×1080 px | 144 Hz | 300 cd/m² | 90 % sRGB | G-SYNC | non-glare
  • 15.6″ OLED | 3840×2160 px | 60 Hz | 400 cd/m² | 100 % sRGB/DCI-P3 | colour calibrated (powered by x-rite) | glare

Mobile Intel HM470 Express

Intel Core i7-10870H | 2.2 – 5.0 GHz | 8 cores/16 threads | 16 MB cache | 45 W TDP

  • Intel UHD Graphics 630 | integrated
  • NVIDIA GeForce RTX 3070 Max-Q | 8 GB GDDR6 | 90 W TGP (+ 15 W Dynamic Boost) | dedicated
  • NVIDIA GeForce RTX 3080 Max-Q | 16 GB GDDR6 | 90 W TGP (+ 15 W Dynamic Boost) | dedicated

Internal Display connection: NVIDIA Optimus
Internal G-SYNC display connection: direct or via NVIDIA Optimus (MUX switch)
HDMI, Mini DisplayPort, DP via USB-C connection: direct
Up to 3 external displays addressable

VR Ready

2x DDR4 SO-DIMM, Dual Channel, up to 64 GB and 3200 MHz

  • 1x M.2 2280 SSD via PCI Express 3.0 x4 (supports RAID 0/1) or SATA III
  • 1x M.2 2280 SSD via PCI Express 3.0 x4 (supports RAID 0/1)
  • High Definition Audio
  • S/PDIF-out (optical)
  • Microphone with noise cancelling
  • Stereo speakers
  • Sound Blaster Atlas

Keyboard with per-key RGB backlight and numeric keypad

  • 1x Thunderbolt 3/USB-C 3.2 Gen2 (DisplayPort: yes, G-SYNC compatible | Power Delivery: no)
  • 3x USB-A 3.2 Gen1 (1x powered)
  • 1x Mini DisplayPort 1.4 (G-SYNC compatible)
  • 1x HDMI 2.1 (with HDCP 2.3)
  • 1x Headphone-out (smartphone-headset compatible)
  • 1x 2-in-1-Audio (Mic-in + S/PDIF optical)
  • 1x RJ45 Port (LAN)
  • 1x UHS-II card reader (microSD/-SDHC/-SDXC)
  • 1x DC-in
  • Realtek Gbit LAN
  • WLAN 802.11a/b/g/n/ac/ax + Bluetooth 5
  • HD webcam
  • Kensington Lock
  • TPM 2.0 (via Intel PTT)

180 watts (145 x 75 x 23 mm | 620 g incl. EU power cable)

  • Changeable 73 Wh Li-Ion-battery (internally screwed)
  • Flexible battery charging function can be activated in BIOS (FlexiCharger)
  • Display lid, top and bottom case made of aluminium
  • Display frame made of plastic
  • 130° display opening angle
  • One-hand opening

ca. 1.99 kg

357.5 x 238 x 19.8 mm (W x D x H)

Laptop (incl. battery), power supply, driver CD/USB-Stick, manual

We continuously provide you with the latest driver versions in the download portal of our company headquarters Schenker Technologies GmbH.

Download here
