XMG APEX 16

INFERNO'S CHAMPION

A strong gaming package combining AMD and NVIDIA power: high-end processors with 16 cores and a fast GeForce RTX 5070 with a generous 12 GB of VRAM make the well-equipped XMG APEX 16 a great price-to-performance choice for ambitious gamers.

At the same time, the laptop impresses with numerous premium features. These include a high-quality display with a 300 Hz refresh rate and full coverage of the extended DCI-P3 colour space, as well as a wide range of cleverly placed ports. Additional high-end features include up to 96 GB of upgradeable RAM and 16 TB of SSD storage, a 99.8 Wh battery, a full-size keyboard with per-key RGB and a first-class typing experience, and the XMG Control Center for individual system tuning.

Neo 16 A25 ist mit dem 9955HX3D
der schnellste Gaming-Laptop

notebookcheck.com

"Alles in allem gibt es hier einen sehr guten Gamer zum fairen Preis."

notebookcheck.com

Wähle Deinen Pfad

GAMER

CREATOR

Kraftvolles, cleanes Design

Stabiles Aluminium-Gehäuse mit RGB-Akzenten

Gaming auf Desktop-Niveau

Der schnellste 16-Zoll-Laptop der Welt

Das schnellste Display seiner Klasse

300 Hz schnelles Mini-LED-
Display mit 1000 Nits

Noch leiser, kühler, schneller mit XMG OASIS

Optionale Wasserkühlung für anspruchsvolle Nutzer

Bereit für alle Aufgaben

Mächtiges Kühlsystem für dauerhafte Höchstleistung

Immer der Erste auf dem Server

Die schnellsten SSDs und Arbeitsspeicher

Maximale Präzision in Millionen Farben

Anti-Ghosting, N-Key-Rollover, Per-Key-RGB

Deine voll ausgestatte Anschlusszentrale

Smarte Platzierung vieler Ports an der Rückseite

Zuverlässiger Dauerläufer

Riesiger 99,8-Wh-Akku mit einstellbarem Verschleißschutz

Dein Laptop - Deine Freiheit

Control Center mit umfangreichen
Individualisierungs-Optionen

Hochwertig, elegant, kompakt

Präzise gefertigtes, robustes Aluminium-Gehäuse

Grenzenloses Kreieren

Der schnellste 16-Zoll-Laptop der Welt

100-prozentige Farbgenauigkeit

Entspiegeltes Mini-LED-
Display mit 1000 Nits

Noch leiser, kühler, schneller mit XMG OASIS

Optionale Wasserkühlung für anspruchsvolle Nutzer

Bereit für alle Aufgaben

Mächtiges Kühlsystem für dauerhafte Höchstleistung

Endlich keine Einschränkungen mehr

Bis zu 96 GB RAM und 16 TB SSD für die komplexesten Projekte

Fokus auf Ergonomie und Funktionalität

Konkave Keycaps, abgesetzte Pfeiltasten, Fn-Lock

Goodbye Dongle Life

Alle Anschlüsse, die Du brauchst – inklusive pfeilschnellem SD-Kartenleser

Zuverlässiger Dauerläufer

Riesiger 99,8-Wh-Akku mit einstellbarem Verschleißschutz

Dein Laptop - Deine Freiheit

Control Center mit umfangreichen Individualisierungs-Optionen

AMD Ryzen HX Processors

Maximum Performance with 16 Cores

Desktop DNA Inside

With the powerful AMD Ryzen 9 9955HX (Fire Range) or the fast Ryzen 9 8945HX (Dragon Range Refresh) at an attractive price, the XMG APEX 16 delivers uncompromising CPU performance. Both high-end processors feature 16 full cores and 32 threads and belong to the HX series – laptop CPUs designed on the same architecture as AMD’s most powerful desktop processors.

NVIDIA GeForce RTX 5070 12 GB

Strong 3D Performance

Future-Proof with 12 GB VRAM

In the XMG APEX 16, NVIDIA’s GeForce RTX 5070 comes in the refreshed version with a generous 12 GB instead of just 8 GB of graphics memory, offering a strong foundation for immersive AAA gaming. Thanks to its 50 percent larger memory, this high-performance laptop GPU delivers stable FPS at high settings on the 1600p display – helped along by modern features such as the latest DLSS (Deep Learning Super Sampling) with Multi Frame Generation. With 4608 CUDA cores and AI capabilities powered by fifth-generation tensor units, it also significantly speeds up professional content-creation software.

Up to 96 GB RAM and 16 TB SSD Storage

Uncompromising Memory Options

Upgradeable at Any Time

With up to two M.2 SSDs, you’ll have plenty of room for all your games. The primary drive is already connected via PCI Express 5.0 x4 for groundbreaking performance: ideal for ultra-fast load times in games that support Microsoft Direct Storage. You can also equip the XMG APEX 16 with fast, socketed DDR5 memory, which can be upgraded at a later date – just like the SSDs.

1600p Display with 500 Nits

Crisp and Bright

Lightning-Fast 300 Hz Gaming

The XMG APEX 16’s high-resolution 16-inch display not only presents your games in razor-sharp detail but also impresses with a generous 500 nits. This keeps it easy to read even in well-lit environments. The fast 300 Hz refresh rate ensures extremely smooth visuals for high-FPS gaming.

100 % sRGB and DCI-P3

With 100 percent coverage of the sRGB and DCI-P3 colour spaces, the anti-glare IPS panel also excels in professional use. Alongside the practical 16:10 aspect ratio, which provides extra screen space for toolbars and other elements, the 180-degree hinge makes presentations easy with the laptop fully opened.

Top Connectivity with Rear Ports

All the Connections You Need

Goodbye Dongle Life

The XMG APEX 16 not only offers an extensive range of external ports but also distributes them cleverly. Located on the rear are HDMI 2.1, Mini DisplayPort 2.1, the power socket, and a USB-C port, which also supports optional charging via a USB-C travel power adapter with up to 140 watts. Additional ports on the sides include three USB-A ports, a second USB-C port, 2.5 Gigabit Ethernet, a high-speed SD Express compatible card reader, and a 2-in-1 audio jack for headsets. The Full HD webcam features a physical privacy shutter and an infrared sensor for seamless Windows Hello sign-in.

Four Native Display Connectors

Perfect for Multi-Monitor Setups

Enhance your creative workflow with a multi-monitor setup, or enjoy smooth gaming and streaming at the same time. Thanks to Mini DisplayPort 2.1, HDMI 2.1, and two USB-C ports with integrated DisplayPort functionality, you can natively connect up to four additional external monitors.

Four Native Display Connectors

Perfect for Multi-Monitor Setups

Premium Keyboard

Total Control with a Full-Size Layout

Per-Key-
RGB

N-Key Rollover

Anti-Ghosting

Precision Tool

The backlit, full-size keyboard puts all the comfort features you need at your fingertips. Gamers benefit from freely programmable per-key RGB lighting, anti-ghosting, and N-key rollover, while creatives enjoy a full four-row numeric keypad, full-size offset arrow keys, concave keycaps, and a quick-switch Fn lock via the ‘Fn’ + ‘ESC’ key combination. Thanks to the improved stability of the key mechanism, the keyboard guarantees an outstanding typing experience and maximum precision.

XMG Control Center and BIOS Tuning

All Settings at Your Fingertips

Fine Tuning for Advanced Users

The powerful XMG Control Center gives you complete control over your laptop’s performance settings – from pre-defined, customised profiles that let you select the ideal balance of performance, noise, and temperature at the touch of a button, to creating custom profiles and manual tuning options. This lets you push your laptop’s high-end components to the max and take the power limits right to the edge.

VIDEOS & TESTS

"Alles in allem gibt es hier einen sehr guten Gamer zum fairen Preis."

NotebookCheck

TECHNICAL DETAILS

Expand all Close all

Product ID

XAP16M26

Displays

16-inch IPS | 2560×1600 px | 16:10 | 300 Hz | 500 nits | 100 % sRGB/DCI-P3 | VRR | non-glare

factory-calibrated colour profiles can be downloaded and set via Control Center
alternatively 60 or 240 Hz settable; maximum 240 Hz with NVIDIA Optimus enabled
variable refresh rate range: 50 to 240 Hz (only with NVIDIA Optimus enabled)

Processors

AMD Ryzen 9 9955HX | Zen 5 | 16 cores, 32 threads | up to 5.4 GHz | 64 MB L3 cache
AMD Ryzen 9 8945HX | Zen 4 | 16 cores, 32 threads | up to 5.4 GHz | 64 MB L3 cache

Graphics

integrated (iGPU):
AMD Radeon 610M | 2 cores | up to 2.2 GHz

dedicated (dGPU):
NVIDIA GeForce RTX 5070 Laptop | 12 GB GDDR7 | 100 W TGP (+ 15 W Dynamic Boost)

Display connection

internal display connection:
iGPU with NVIDIA Optimus or dGPU (via MUX switch)

DisplayPort 1.4a via USB-C connection (2x):
iGPU with NVIDIA Optimus

HDMI 2.1 and Mini DisplayPort 2.1 connection:
dGPU

four external displays directly addressable
additional external displays possible with docking station/adapter
supports NVIDIA G-SYNC and AMD FreeSync
VR Ready

Cooling system

composite cooling system with copper heatpipes
two fans, each 80 mm in diameter, 10 mm in height and with 99 fan blades
third fan with 47 mm in diameter, 5 mm in height and with 67 fan blades for RAM cooling
two air outlets with a total of 150 copper cooling fins
air intake via bottom case and keyboard
PTM7958 phase change thermal compound on CPU and GPU

Power limits

CPU + GPU: 200 watts (sustained)
GPU-only: 115 watts (sustained)
CPU-only: 135/130 watts (for up to 3 minutes/sustained) with AMD Ryzen 9 9955HX
CPU-only: 125/115 watts (for up to 60 seconds/sustained) with AMD Ryzen 9 8945HX

_{Thermals and sustained power limits may vary with room temperature and airflow.
Values represent average capabilities under normal conditions.}

Firmware features

with AMD Ryzen 9 9955HX: manual CPU undervolting and RAM tuning, incl. recovery function

Software features

advanced Control Center with customisable power limits, fan curves, display profiles (incl. blue light filter) etc.
power profiles can be changed quickly via a dedicated button (three predefined and one customised)
Windows installation without additional third-party software (for configurations with operating system)

Memory

2x DDR5 SO-DIMM | Dual Channel | max. 96 GB | max. 5600 MT/s | max. 1.1 V (with AMD Ryzen 9 9955HX)
2x DDR5 SO-DIMM | Dual Channel | max. 96 GB | max. 5200 MT/s | max. 1.1 V (with AMD Ryzen 9 8945HX)

Storage

1x M.2 2280 SSD via PCI Express 5.0 x4
1x M.2 2280 SSD via PCI Express 4.0 x4
supports RAID 0/1

Audio

stereo speakers
Nahimic by SteelSeries Software
microphone with noise cancellation
Full HD webcam (Windows Hello compatible)

Keyboard

keyboard with per-key RGB backlight, concave keycaps, fully-fledged numeric keypad, dedicated navigation keys,
full-size arrow keys, N-key rollover, anti-ghosting and Fn lock function
dedicated performance mode switch button above keyboard

Tochpad

Microsoft Precision Touchpad, integrated buttons| 123 x 77.5 mm (W x D)
innovative surface material with optimised glide characteristics
automatic palm detection to avoid false inputs
supports scrolling, tapping, swiping and other multi-finger gestures as defined by operating system

Ports (clockwise)

Left:

2-in-1-audio (headphone + mic)
USB-A 3.2 Gen1 (5 Gbps)
USB-C 3.2 Gen2 (10 Gbps | DisplayPort 1.4a with 32.4 Gbps | 100 W Power Delivery)¹⁾
RJ45 Port (2.5 GbE)

Rear:

HDMI 2.1 (48 Gbps | HDCP 2.3 | VRR/G-SYNC)
Mini DisplayPort 2.1 (DP80/UHBR20)²⁾
DC-in (5.5/2.5 x 12.5 mm; IEC 60130-10)
USB-C 3.2 Gen2 (10 Gbps | DisplayPort 1.4a with 32.4 Gbps | 140 W Power Delivery)¹⁾

Right:

full-size card reader (SD/SDHC/SDXC | SD Express | UHS-II)³⁾
2x USB-A 3.2 Gen1 (5 Gbps)

_{¹⁾ USB-C 3.2 Gen2
connection via iGPU (MSHybrid | NVIDIA Optimus)
USB Power Delivery left: exclusively with 20V/5A (100 watts)
USB Power Delivery rear: from 20V/5A (100 watts) to 20V/7A (140 Watt)
power supply for peripherals: max. 5V/3A (15 watts)
one DisplayPort stream
supports NVIDIA G-SYNC (Compatible) and AMD FreeSync}

_{²⁾ Mini DisplayPort 2.1
connection via dGPU
one DisplayPort stream
dual mode (DP++)
supports NVIDIA G-SYNC (all variants) and AMD FreeSync
supports VR headsets}

_{³⁾ Read/write speeds card reader
SD Express up to 900/500 MB/s
SDXC UHS-II up to 270/230 MB/s}

Network
