XMG FOCUS 15 Gaming-Laptop Keyvisual

XMG FOCUS 17

All-round carefree package with a large display for a successful entry into the world of gaming: the XMG FOCUS 17 combines the modern power of Intel’s Core i7-11800H with eight cores and NVIDIA’s GeForce RTX 3050 Ti as an entry-level option into the ray-tracing class, to form an action-packed duo. A slim design and light weight of just 2.4 kg for a 17.3-inch gaming laptop make for attractive, portable features. At the same time, the clearly structured and modern design offers subdued elegance. Maximum input comfort comes in the form of a precise keyboard with a practical number pad, large arrow keys and multi-level adjustable backlighting, which also offers the choice of different LED colours.

XMG FOCUS 15 Gaming-Laptop Intel Prozessor mobile

Future-proof eight-core power

INTEL CORE i7-11800H

Powerful: with eight cores and 16 threads, Intel’s Core i7-11800H is ideally prepared to meet future demands with ease. The processor from the 11th Core generation is one of the top models in Intel’s current mobile lineup and doesn’t just impress with its powerful gaming performance. Due to the high number of processing cores and the associated performance reserves, it is also ideally suited for simultaneous gaming and streaming.

XMG PRO 15 Audio DJ-Laptop

Raytracing unlocked

GEFORCE RTX 3050 Ti

Built around the GeForce RTX 3050 Ti, the XMG FOCUS 17 offers an optimal entry into the new ray tracing class with breathtaking graphic effects – so you won’t miss any details! The graphics card is the perfect solution for popular games such as Minecraft and Fortnite with RTX ON, or Rocket League and FIFA with high FPS values. NVIDIA’s DLSS 2.0 technology (Deep Learning Super Sampling) ensures a balance between smooth gameplay and high quality visuals.

XMG FOCUS 15 Gaming-Laptop NVIDIA RTX
XMG FOCUS 17 Gaming-Laptop Display

High-quality & fast

IPS display with 144 Hz

The high-quality IPS panel of the XMG FOCUS 17 impresses with its first-class display and leaves nothing to be desired. Bright, intense colours, excellent black levels and contrasts as well as a high viewing angle stability are among the outstanding display features. In fast action games, the Full HD display (1920 x 1080 pixels) excells with exceptionally smooth playback thanks to a refresh rate of 144 Hz.

Powerful soundscapes

Optimal headphone sound

To give you the best possible sound through your headphones and maximise your immersive gaming experience, the XMG FOCUS 17 uses Creative Sound Blaster technology for optimal sound adjustment. The Sound Blaster Cinema 6 app gives you access to a wide range of setting options, allowing you to call up the ideal sound profiles for gaming, videos or music and customise them to your taste.

XMG FOCUS 17 Gaming-Laptop Sound Blaster Cinema 6
XMG FOCUS 15 Gaming-Laptop Speicher

Generous

MEMORY

MEMORY

Thanks to its flexible memory options, the XMG FOCUS 17 can be perfectly tailored to your individual requirements. The laptop offers two SO-DIMM slots and can hold up to 64 GB of DDR4-3200 memory. It also offers space for an lightning-fast NVMe SSD in M.2 format as well as a complementary 2.5 inch drive. Retrofitting the storage components is effortless, as the inside of the chassis is easily accessible.

XMG FOCUS 15 Gaming-Laptop Speicher
XMG FOCUS 15 Gaming-Laptop Ports

Wide-ranging

Connectivity

A wide range of external connections makes the XMG FOCUS 17 a flexible everyday companion. These include four USB ports including USB-C as well as a Mini DisplayPort and an HDMI output for graphics output to additional external monitors. Furthermore, the laptop scores with a wired network connection, wireless Wi-Fi 6, a full-size SD card reader and separate audio connections – once for an individual microphone and once for classic headphones or a headset.

XMG FOCUS 15 Gaming-Laptop Ports
VIDEOS & TESTS
Play Video
TECHNICAL DETAILS

XFO17M21

17.3″ IPS | 1920×1080 px | 144 Hz | 300 cd/m² | 90 % sRGB | non-glare

Intel HM570

Intel Core i7-11800H | 2.3 – 4.6 GHz | 8 cores/16 threads | 24 MB cache | 45+ W TDP

  • Intel UHD Graphics | integrated
  • NVIDIA GeForce RTX 3050 Ti Laptop GPU | 4 GB GDDR6 | 60 W TGP (+15 W Dynamic Boost) | dedicated

Display, HDMI, Mini DisplayPort connection: Intel UHD Graphics (with NVIDIA Optimus) No G-SYNC support

2x DDR4 SO-DIMM, Dual Channel, up to 64 GB and 3200 MHz

  • M.2 2280 SSD via PCI Express 3.0 x4
  • 2.5″ SSD/HDD (7 mm)
  • Stereo speakers
  • Microphone with noise cancelling
  • Sound Blaster Cinema 6

Backlit keyboard with numeric keypad, 15 colour options

Microsoft Precision Touchpad, two integrated buttons

Left:
Headphone-out (smartphone headset compatible)
Mic-in
USB-A 2.0
USB-A 3.2 Gen1

Rear:
DC-in
HDMI 2.0 (with HDCP 2.2)
Mini DisplayPort 1.4

Right:
RJ45 Port (LAN)
USB-A 3.2 Gen1
USB-C 3.2 Gen2×1 (DisplayPort: no | Power Delivery: no)
Card reader (SD/SDHC/SDXC)

  • Realtek Gbit LAN
  • WLAN 802.11a/b/g/n/ac/ax + Bluetooth 5
  • HD webcam
  • Kensington Lock
  • TPM 2.0 (via Intel PTT)

150 watts (128 x 66 x 22 mm | 555 g incl. EU power cable)
Flexible battery charging function can be activated in BIOS (FlexiCharger)

Changeable Li-poly battery with 49 Wh (internally screwed)

  • Plastic
  • 130° display opening angle

ca. 2.4 kg

396.9 x 262 x 23.5 mm (W x D x H)

Laptop (incl. battery), power supply, driver USB stick

We continuously provide you with the latest driver versions in the download portal of our company headquarters Schenker Technologies GmbH.
