XMG APEX 15Gaming-Laptop

XMG APEX 15 – KING OF THE HILL





High-performance gaming at an attractive price: the powerfully dominant XMG APEX 15 packs fast ray-tracing graphics cards up to NVIDIA GeForce RTX 3070 and Ryzen 5000 eight-core processors from AMD into a sturdy chassis with a bold gaming design. The ample air outlets of the robust base unit allow the powerful components to breathe freely even under full load, whilst an aluminium display lid provides additional stability. Thus, the laptop provides you with indomitable, durable gaming power at a high level. If you are looking for the perfect entry into the performance upper class that concentrates on the essentials and delivers high FPS, then the XMG APEX 15 has everything you need!

Full HD IPS Display

144 Hz | 300 cd/m² | 90 % sRGB

max. AMD Ryzen 9 5900HX

3.3 – 4.6 GHz | 8 Cores/16 Threads

XMG APEX 15 M21 Gaming-Laptop front

max. NVIDIA RTX 3070

8 GB GDDR6 | 140 W TGP

max. 64 GB RAM

2x SO-DIMM DDR4 | 3200 MHz

Fast gaming display:
IPS panel with 144 Hz

A high-quality IPS display reproduces your games in the best possible quality: with its intense colours, excellent black levels and contrast as well as exceptional viewing angle stability, the Full HD panel (1920 x 1080 pixels) of the XMG APEX 15 scores with first-class display characteristics. Gamers in particular benefit from the high refresh rate of 144 Hz. This allows fast action titles, among others, to run particularly smoothly.

Eight high-end cores:
AMD Ryzen 5000 processors

On the processor side, the XMG APEX 15 delivers nothing less than mobile high-end performance. AMD’s Ryzen 7 5800H and the even stronger Ryzen 9 5900HX are among the fastest eight-core processors with a full 16 threads. The modern CPUs are not only characterised by optimal performance for elaborate AAA games and simultaneous streaming, but also excel with very high application performance.

Ray tracing for advanced users:
Fast RTX-3000 graphics cards

With the latest ray-tracing-capable graphics cards from NVIDIA, the XMG APEX 15 is ready for higher tasks. A powerful GeForce RTX 3070 with 8 GB GDDR6 graphics memory is available as the top option, while the RTX 3060 with 6 GB GDDR6 as an entry-level option already offers very high Full HD gaming performance. To call upon the maximum specified performance in each case, the graphics cards operate in the highest possible TGP expansion stage.

Future-proof & upgradeable:
Up to two SSDs and 64 GB RAM

The XMG APEX 15 allows individual RAM and SSD configurations to perfectly meet your requirements. The gaming laptop is equipped with two M.2 slots for fast NVMe SSDs with PCI Express connection. You are also well equipped for the future with up to 64 GB of DDR4-3200 RAM. The RAM modules are plugged in, not soldered, and just like the two M.2 slots are easily accessible via the removable bottom shell. This facilitates subsequent upgrade options and maintenance of the laptop.

Well equipped:
Three monitor ports & 2.5 Gigabit Ethernet

Thanks to three external graphics interfaces, the XMG APEX 15 is optimally prepared for the use of a multi-monitor setup or for connecting a VR headset. It can also simultaneously address up to three external monitors in addition to the internal display. As well as the integration of a DisplayPort stream into the USB-C port, the laptop has a Mini DisplayPort and an HDMI output. All three are directly connected to the GeForce RTX graphics card for optimal VR headset compatibility and are located at the rear of the laptop, as is the fast 2.5 Gigabit Ethernet port.

Immersive gaming:
Rich sound for the headset

For connecting your gaming headset or other audio peripherals, the XMG APEX 15 has both a headset-compatible 2-in-1 audio port and a separate microphone input. For optimal audio, Creative’s Sound Blaster technology allows you to fully customise the sound. The Sound Blaster Cinema 6 app provides a precise tool for selecting and adjusting specific sound profiles for gaming, watching videos or listening to music.

Display

15.6″ IPS | 1920×1080 px | 144 Hz | 300 cd/m² | 90 % sRGB | non-glare

Processors

AMD Ryzen 7 5800H | 3.2 – 4.4 GHz | 8 cores/16 threads | 16 MB cache | 54 W TDP
AMD Ryzen 9 5900HX | 3.3 – 4.6 GHz | 8 cores/16 threads | 16 MB cache | 54 W TDP

Graphics

AMD Radeon RX Vega 7 | integrated
NVIDIA GeForce RTX 3060 Laptop GPU | 6 GB GDDR6 | 115 W TGP (+15 W Dynamic Boost) | dedicated
NVIDIA GeForce RTX 3070 Laptop GPU | 8 GB GDDR6 | 125 W TGP (+15 W Dynamic Boost) | dedicated



Display connection: AMD Radeon RX Vega 7 (with NVIDIA Optimus)
HDMI, Mini DisplayPort, DisplayPort via USB-C connection: direct
3 external displays directly addressable (more with MST adapter via USB-C or Mini DisplayPort )



VR Ready

Memory

2x DDR4 SO-DIMM, Dual Channel, up to 64 GB and 3200 MHz

Storage

2x M.2 2280 SSD via PCI Express 3.0 x4

Sound

Stereo speakers
Microphone with noise cancelling
Sound Blaster Cinema 6

Keyboard

Backlit keyboard with numeric keypad, 15 colour options

Touchpad

Microsoft Precision Touchpad, two integrated buttons

Communication

Realtek 2.5 Gbit LAN
Wi-Fi 802.11a/b/g/n/ac/ax + Bluetooth 5
HD webcam

Ports
(clockwise)

Left:
USB-A 3.2 Gen1
USB-A 3.2 Gen2×1
DC-in



Rear:
USB-C 3.2 Gen2×1 (DisplayPort 1.4: yes, G-SYNC compatible | Power Delivery: no)
RJ45 2.5 Gbit Port (LAN)
HDMI 2.0 (with HDCP 2.3)
Mini DisplayPort 1.4 (G-SYNC compatible)



Right:
USB-A 2.0
Headphone-out (Smartphone headset compatible)
Mic-in

Security

Kensington Lock
TPM 2.0 (via dTPM)

Chassis

Display lid made of aluminium
Display frame, top and bottom case made of plastic
130° display opening angle

Dimensions

361 x 258 x 29 mm (W x D x H)

Weight

ca. 2.1 kg

Power supply

230 watts (155 x 75 x 30 mm | 805 g incl. EU power cable)

Battery

Changeable 49 Wh Li-poly battery
Flexible battery charging function can be activated in BIOS (FlexiCharger)

Included in box

Laptop (incl. battery), power supply, driver USB stick
